Key Features
1. Powder-Coated Slide Ready: Installs directly on traditional slides (bypasses need for specialized rails).
2. SnapAlign™ Clip: Laser-guided alignment ensures perfect damper positioning in 3 seconds – zero measurement needed.
3. Tool-Free Mounting: Locking levers secure to slide grooves without screws.
4. Wide Compatibility: Fits 90% side/undermount slides (10-30KG drawer weight).
5. SilentPro™ Hydraulics: Whisper-quiet closure at <15dB.
6. Compact & Durable: Zinc-alloy core + polymer shell for 150,000+ cycles.
7. Anti-Pinch Safety: Prevents finger injuries with controlled deceleration.
Product Specifications
| Parameter | Value |
| Dimensions (L×W×H) | 58 × 18 × 12 mm |
| Drawer Weight Range | 10-30KG |
| Slide Thickness | 1.0-1.8mm (powder-coated/standard) |
| Damping Force | 80N (adjustable via end cap) |
| Operating Temp | -20°C to 70°C |
| Cycle Life | 150,000 cycles (tested) |
| Installation Time | <1 minute per damper |
Why This Beats Competitors?
✅ No Slide Replacement: Works on existing slides – saves 80% vs. buying new soft-close slides.
✅ Precision Without Tools: SnapAlign clip eliminates misalignment errors (unlike screw-based dampers).
✅ No Drilling: Slide-groove locking system preserves drawer integrity.
✅ Scale Fast: Install 20+ drawers/hour with pre-calibrated clips.
Applications
- Kitchen Cabinets: Upgrade standard drawers to premium soft-close.
- Office Furniture: Silent file/desk drawers in workspaces.
- Retail Displays: Protect jewelry/store merchandise drawers.
- KEA/Hackable Furniture: Retrofit budget furniture with high-end function.
How SnapAlign™ Works
1. Clip the damper onto slide rail (alignment teeth auto-center position).
2. Press locking levers until "click" confirms grip on slide groove.
3. Test drawer – damper activates on final 15% of closing motion.
Packaging & Payment
- Packaging: Recyclable blister packs (50 sets/carton; 1 damper + 1 SnapAlign clip).
- MOQ: 5,000 pcs
- Delivery: 10 days after deposit
- Payment: 30% deposit, 70% before shipment
- Customization: OEM branding on clips, damper color (white/black/grey).
Technical Innovation
Dual-Axis Grip System" – Spring-loaded jaws grip both slide edges (top/bottom), preventing lateral shift during heavy use.
