Key Features
1. Ghost Door Optimized: 3.5mm ultra-slim profile maintains invisible hardware aesthetics.
2. Moisture-Resistant: IPX4-rated seals protect against bathroom steam and splashes.
3. Bidirectional Damping: Single-unit control for both push/pull motions (no rebound).
4. Wide Weight Range: Supports 5-40KG hollow-core, glass, or composite doors.
5. Tool-Free Clip Mount: Snap-on installation for tracks (no screws/drilling).
6. Zero Gap Design: Flush-mount mechanism prevents dust trapping in partitions.
7. QuietTouch™ Tech: Silicone-embedded hydraulics for 15dB silent operation.
Product Specifications
| Parameter | Value/Description |
| Dimensions | |
| Length | 180 mm |
| Width | 3.5 mm (visible) / 12 mm (core) |
| Height | 8.2 mm |
| Door Weight | 5-40KG |
| Temperature Range | -20°C to 80°C (high-temp upgrade) |
| Cycle Life | 200,000 cycles (50% > industry) |
| Water Resistance | IPX4 (splash-proof) |
| MOQ/Delivery | 5,000 pcs / 10 days |
Applications
- Ghost Door Systems: Hidden damping for frameless floating doors
- Office Partitions: Noise-free sliding for modular cubicles
- Bathroom/Shower: Steam-resistant buffering in wet rooms
- Hollow-Core Sliders: Prevents lightweight door wobble
- Retail Display Panels: Smooth motion for glass product displays
Notes
- Includes universal mounting kits for overhead tracks (glass, aluminum, steel).
- Customizable spring tension and hook sizes available for OEM/ODM orders.
Technical Innovation
> "Patented Parallel Hydraulic Cartridge" – Dual micro-hydraulic cylinders work in tandem to eliminate lateral friction, enabling unmatched slimness (60% thinner than standard dampers) while handling 4x heavier loads than competitors in its class.
Packaging & Ordering
- Packaging: Vacuum-sealed anti-oxidation trays (100 pcs/carton)
- Payment: 30% deposit, 70% before shipment
- Customization: OEM laser engraving, PVD finishes (black/gold/chrome)
